Motor Power 50W Single Swing Gate Operator Kit

This motor power 50W single swing gate operator kit is applicable to single leaf gate weight less than 300kg (660lbs), and the length shorter than 3m (10ft). The drive mode adopts planetary transmission to combine with the screw rod transmission. This gate opener must be installed inside the enclosure or yard for protection.

Send Inquiry

Add To Inquiry

Motor Power 50W Single Swing Gate Operator Kit Introduction

Swing Gate Motor_

This heavy duty swing gate operator is designed for residential and commercial applications. All the gate operators supplied are pre tested and of good quality long lasting and have a 12 Months back to base warranty on the complete system.

Technical Parameters

Model	SW300DC
Power supply	110V/60Hz
Motor power	50W
Gate moving speed	18~22s / 90°
Max.single-leaf weight	300kg
Max.single-leaf length	3M
Max.piston stroke	32cm
Max.force	2800N
Remote control distance	≥30m
Remote control mode	Single/Three button mode
Storage battery (optional)	DC24V (4.5Ah or 9Ah)
Noise	≤58dB
Recording of up remote controls	32
Remote frequency	433.92 MHz
Working temperature	-20°C - +70°C

KIT FEATURES:

●Travel self-learning after motor correctly installed.

●Soft start and slow stop.

●Automatic reverse after encountering obstacles.

●Automatic close with waiting time adjustable.

●Solar system compatible.

●Single swing mode for quick entering and departure.

Product Size

Automation for Swing Gate_

electric motor power 50W swing gate motor
