Chain Drive Gate Automation
The DKC500ACL sliding gate opener is applicable to gates with weight less than 600KG, and length less than 12m. The gate opener is driven by the sprocket and chain transmission. This gate opener must be installed inside the enclosure of your property for safety.
Sliding Gate Opener (model DKC500ACL) Introduction
The DKC500ACL sliding gate opener is applicable to gates with weight less than 600KG, and length less than 12m. The gate opener is driven by the sprocket and chain transmission and must be installed inside the enclosure of your property for safety.
Technical parameters
Model | DKC500ACL |
Power supply | 110VAC/60Hz |
Motor power | 280W |
Gate moving speed | 13m/min |
Remote control distance | ≥ 100ft |
Remote control mode | Single / Three button mode |
Limit switch | Mechanical / Magnetic limit switch |
Noise | ≤ 56dB |
Working duty | S2, 20min |
Recording of maxium remote controls | 40 |
Frequency | 433.92 MHz |
Working temperature | -20°C ~ +70°C |
Gate Preparation
Ensure that the sliding gate is correctly installed.
The gate is horizontal and level and the gate can glide back and forth smoothly when moved by hand before installing the gate opener.
Wheels and guide rollers should rotate easily and be free from dirt or grime.
Track should be flat, level and firmly affixed.
Any misalignment in the gate will affect performance of the automatic gate opener.
Function
Soft Start and slow stop
Automatic reverse after encountering obstacles
Motor output force, stall force, slow stop distance are adjustable
Automatic close with waiting time adjustable
Partial openning for pedestrian passes
