The Selection Of Courtyard Swing Door Machine Mainly Considers Seven Factors

The swing door motor is the key to choosing a swing door automation system. The automatic door opening machine for a courtyard usually consists of 1-2 motors, controllers, control devices, and safety devices. This article will discuss the types of gantry cranes, component combinations, and practical usage needs, teaching everyone how to choose a suitable swing door crane.
1, The width and weight of the door leaf (the primary factor in selection) are the maximum load-bearing capacity and applicable door width range of each door machine model. Generally, heavier or wider door leaves require stronger door machines to ensure smooth opening and closing of the door.
2, The design of door leaves and pillars can also affect the choice of gantry crane. The installation dimensions of the door frame are considered in the design of the door leaf and door post to avoid damaging the door post and modifying the door body during the later installation of the door frame.
3, For some models of door openers, the motor needs to be installed with a mechanical door stopper at the closing or opening position before it can be used.
4, If the door opens inward, the distance from the hinge to the door post (dimension "A") should be considered for the direction and angle of the door opening. If the door opens outward, the installation distance from the hinge to the motor rear bracket (distance "B") should be considered. Another aspect of the interior opening is the opening angle. The maximum opening angle varies for different door machine models, and it is generally recommended to open the interior by 120 degrees and the interior by 90 degrees.
5, Most door openers can open the door to 90 degrees within 15-30 seconds. The speed of opening the door should be based on the fast model of the door opener. However, if the speed of opening the door is too fast, it may cause safety hazards. Therefore, when choosing, it is necessary to balance safety and convenience.
6, When installing a buried swing door machine, specific conditions must be followed. When installing the buried swing door motor, the following conditions must be followed: the distance between the gate and the ground and the size of the gate hinge need to meet the installation requirements of the buried swing door machine. The buried box needs to be equipped with drainage pillars and the buried box should use the same installation foundation. Although the buried swing door machine is beautiful (the motor is hidden) and has a large opening angle, the installation is more complex and requires planning in advance. According to different application requirements and installation environments, swing door openers can be divided into several types: straight arm, curved arm, and buried. The straight arm curved arm buried swing door machine has good aesthetics and can achieve an opening angle of 120 to 180 degrees. It is suitable for applications that require aesthetics and large opening angles, but it needs to be planned in advance. In contrast, straight arm and curved arm door openers are more common and suitable for most standard situations,
7, Generally speaking, the motor type of the drive is 230V AC motor and 24V DC motor. 24V DC motor has high safety and is not easy to overheat, suitable for commercial places or frequent operating environments. Additional backup batteries can be configured to operate during short-term power outages, increasing convenience and safety. Choosing a swing door machine requires consideration of door characteristics, application scenarios, motor types, and system integrity. After evaluating these factors, you can choose the most suitable swing door machine for the project. As a globally renowned brand, CAME's swing door openers have the advantages of international quality assurance, adaptability to harsh environments, support for various door leaf weights and sizes, built-in remote control and obstacle detection functions, seamless connection with smart homes, a full range of door openers, and high-quality after-sales service, making them an ideal choice.
